When MMW Challenges Push the Limits of Design, We Reengineer What’s Possible Micro Harmonics was founded on the clear belief that advancement at millimeter wave (MMW) and terahertz (THz) frequencies requires components designed to resolve industry challenges. We are committed to listening to our customers, learning about their needs, and designing innovative solutions. The pace of innovation in radio astronomy, quantum computing, and high-frequency test [...]

Orthomode Transducers: Part 2 – Architectures David W. Porterfield, PhD Founder, Micro Harmonics In our previous blog, "Orthomode Transducers: Part 1 – Introduction and Applications", we provided an preliminary examination of orthomode transducers (OMTs) and their applications. In this post, we will explore the OMT architecture. OMTs have three waveguide ports. Two ports support a single propagating mode, typically the TE10 mode in a rectangular [...]

Orthomode Transducers: Part 1 – Introduction and Applications David W. Porterfield, PhD Founder, Micro Harmonics Orthomode transducers (OMTs), also known as polarization duplexers, are waveguide components that combine or separate two orthogonally polarized signals. OMTs have three waveguide ports. Two of the ports support a single propagating mode, typically the TE10 mode in rectangular waveguide. The third port, often referred to as the common mode [...]

A mm-Wave Circulator with High Transmitter and Receiver Isolation (Part 2) David W. Porterfield, Ph.D. President and Founder Micro Harmonics Corporation In last month’s blog, I showed why a triple junction circulator offers no advantage over a single junction circulator in isolating a sensitive receiver from a high-power transmitter (S31). I also showed that the new Micro Harmonics hybrid circulators [1] can achieve much higher [...]

A mm-Wave Circulator with High Transmitter and Receiver Isolation (Part 1) Circulators are used in transmit/receive systems to allow a transmitter and receiver to share a common antenna. A circulator schematic is shown in Figure 1, with typical connections for the transmitter (Tx), receiver (Rx), and antenna (Ant). Figure 1 – Schematic for a circulator showing transmitter (Tx), antenna (Ant), and receiver (Rx) connections. The [...]

Are Faraday Rotation Isolators Sensitive to Magnetic Fields? Some Faraday rotation isolators are very sensitive to magnetic fields while others show almost no sensitivity at all. It depends on the magnetic bias point. Faraday rotation isolators employ a magnetically biased ferrite rod. An internal magnet or an array of magnets is used to bias the ferrite. The applied magnetic field aligns magnetic dipoles in the [...]
